PRODUCT SPECIFICATIONS:
◆ Model: DL01 underwater photographing BLUE Light
◆ Bulb: White CREE XP-E D4 LED *10, 455nm (Max 12w)
◆ Runtime:
High Mode: 60mins;
Medium Mode: 150mins;
Strobe 180mins
◆ Reflector: No hotspot design, no reflector;
◆ Lens: 5mm Polycarbonate Board;
◆ Body material: Durable aircraft-grade aluminum;
◆ Angle of light beam: 110°
◆ Surface treatment: Premium Type III hard-anodizing.
◆ Battery: 26650 Rechargeable Li- ion Battery x1 (Optional)
◆ Low Battery Alert
Below 10%: Flash 3 times then step down to Low mode
Below 5%: switch off;
◆ With battery over-discharging protection, polarity reversing
protection
◆ Operation voltage: 2.8V to 4.2V;
◆ Waterproof: 100 meters underwater
◆ Dimensions: 156mm (length)* 50mm (head); 30mm (body)
◆ Weight: 238 grams
◆ Underwater Weight: 141 grams
◆ Impact resistance: 1.5M.
Package includes (with original box)
Archon Flashlight
Archon Ball Arm
Yellow Filter (for Neutral White Light effect)
Lanyard
Spare O-ring
Service Grease
Operation Manual
